200-2000ML water filling machine

The CGF32-32-10 Bottle Water Filling Machine is a versatile solution for mineral water, pure water, and non-gas beverage production. It combines rinsing, filling, and capping functions in one unit, supporting various PET bottle sizes and shapes. Ideal for increasing production efficiency and precision, this machine offers high hygiene standards and easy integration into packaging lines.

Overview
Related Products

Main Technical Parameter

Suitable Products: Mineral water/Pure water/Non-gas wine drink, etc.

Suitable Containers: PET bottles of various capacities and shapes

Filling Methods: Mechanical valve filling, flow meter filling, weight-based filling, or laser level filling

Production Capacity: 2000-30000 BPH

200-2000ML water filling machine

Model	C G F 8 - 8 - 3	C G F 1 6 - 1 2 - 6	C G F 1 8 - 1 8 - 6	C G F 2 4 - 2 4 - 8	C G F 3 2 - 3 2 - 1 0	C G F 4 0 - 4 0 - 1 2	C G F 5 0 - 5 0 - 1 2	C G F 6 0 - 6 0 - 1 5
Capacity (for 500 ML)	2 5 0 0 - 3 0 0 0 B P H	3 5 0 0 - 4 0 0 0 B P H	4 5 0 0 - 6 0 0 0	8 0 0 0 - 1 2 0 0 0	1 2 0 0 0 - 1 4 0 0 0	1 5 0 0 0 - 1 8 0 0 0	2 1 0 0 0 - 2 4 0 0 0	2 6 0 0 0 - 3 0 0 0 0
Suitable bottle shapes	P E T circular or square
Bottle diameter (mm)	5 0 - 1 1 5 mm
Compressor air	0.3 - 0.7 Mpa
Washing meidium	Aseptic water
Rinsing pressure	> 0.06 Mpa < 0.2 Mpa
Total power (KW)	3 . 9 1	4 . 6 1	4 . 6 1	5 . 4 1	6 . 4 1	9 . 6 3	1 2 . 5	1 5
Overall dimensions (m)	3 . 5 * 1 . 7	2 . 2 * 1 . 9	2 . 5 * 2 . 1	2 . 8 * 2 . 2	3 . 5 * 2 . 3	4 * 3	5 . 5 * 4 . 5	7 * 6 . 5
Height (m)	2 . 2	2.2	2.2	2.2	2.25	2.25	2.25	2.25
Weight (kg)	20 0 0	2 5 0 0	3 5 0 0	4 5 0 0	6 0 0 0	8 0 0 0	1 0 5 0 0	1 3 0 0 0

Detailed description

The water filling machine is a versatile system that combines rinsing, filling, and capping functions in one unit. Designed with a suspension mechanism, the CGF water filling machine can easily handle various types of bottles. Primarily used for filling drinking water, it can also be adjusted to fill PET bottles with fruit juice and tea at high temperatures by changing the valve. This flexibility makes it an ideal choice for various beverage production needs. Additionally, the machine can be seamlessly integrated with other equipment to form a complete water filling and packaging production line.


Advantages of the Automatic Liquid Filling Machine

High Efficiency: Automatic liquid filling machines significantly increase production speed and efficiency, reducing the time required to fill containers compared to manual methods.

Precision and Consistency: These machines ensure accurate and consistent filling volumes, minimizing product waste and ensuring uniformity across all filled containers.

Versatility: Designed to handle various types of liquids, from water and juice to more viscous substances, automatic liquid filling machines can be easily adjusted to accommodate different product requirements.

Hygiene and Safety: With automated systems, there is less human contact with the product, which enhances hygiene and reduces the risk of contamination. Additionally, safety features are often built into the machines to protect operators.

Scalability: Automatic liquid filling machines can be easily integrated into larger production lines and scaled up to meet increasing production demands.

Reduced Labor Costs: By automating the filling process, businesses can reduce labor costs and reallocate workforce to other areas of production that may require human intervention.

Ease of Operation and Maintenance: Modern automatic liquid filling machines come with user-friendly interfaces and require minimal maintenance, making them easy to operate and maintain over time.

Customizability: These machines can be customized to fit specific production needs, including different bottle sizes, shapes, and materials, providing flexibility for manufacturers.
