Blowing Molding Machine

Discover the Q series linear bottle blowing machine by Ace Filling, featuring a stable servo control system for high-speed, reliable, and energy-efficient bottle production. This advanced machine boasts a user-friendly microcomputer touch screen for effortless temperature control and precise mold matching, suitable for a variety of bottle types and ideal for continuous production lines. Experience simplified maintenance and reduced operational costs with our innovative blowing molding technology.

Overview
Related Products

Automatic 4 cavity bottle blowing machine

	Item	Q6000
Bottle type specification	Cavity	4
	Output(PCS/HR)	6000-6500
	Max. Volume (L)	2L
	Bottle mouth maximum overall diameter (mm)	28-38mm
	Bottle biggest diameter	100mm
	Bottle maximum height	330mm
Power specifications	Light tube quantity	32PCS
	Light tube power	1.25kw
	Maximum heating power	40kw
	All electric machine installation	43kw
	Actual consumption	21.5kw
Machine specification	Size of the machine	4.5X1.6X1.9 (m)
Machine specification	Weight of the machine	3.5t

Detailed description

Q series linear bottle blowing machine adopts a servo control system, with a stable and reliable structure, high speed, stable, simple maintenance, flexible and convenient mold matching, etc, which can meet the needs of continuous production. Use microcomputer touch screen controls and adjust the temperature, making temperature adjustment of blow molding different bottle types simple. The servo transmission system, has high positioning accuracy, fast speed, good stability and reliability, no need air source, energy saving, and low maintenance cost.
