5 Gallon Water Filling Machine

Efficiently automate your water bottling process with our 5 Gallon Water Filling Machine. Featuring mechanical valve, flow meter, or laser positioning filling modes, this integrated system can produce up to 1200 barrels per hour. Suitable for pure water, mineral water, and more, it ensures a seamless production line from filling to packaging. Boost your production capacity and streamline your operations today!

Overview
Related Products

Gallon-Water Filling Machine

Applicable Products: Pure water, mineral water, etc.
Suitable Container: 5 Gallons (18.9L)
Filling Modes: Mechanical valve filling, flow meter filling or laser positioning filling
Production Capacity: 100 barrels/hour – 1200 barrels/hour

Technical specification

Model	QG F -150	QG F -300	QG F -450	QG F -600	QG F -900
Capacity (for 5 Gallon)	150 BPH	300 BPH	450 BPH	600 BPH	900 BPH
Suitable bottle shapes	PET circular or square
Barrel specification	Ф270X490mm
Filling capacity	10~20L
Air consumption	0.3-0.7Mpa
Rinsing pressure	0.37 m3 /min
Total power (KW)	1.75	3.8	5.5	7.5	9
Overall dimensions (M)	2.5* 1.1	3.9* 1.5	3.9* 1.7	4* 2.1	4.5* 3.5
Height (M)	1.6	1.7	1.7	1.7	3.2
Weight (KG)	800	1 100	1 700	2 500	3 500

Detailed description

This equipment is primarily composed of several integrated components, including a five-gallon automatic adjustment cover machine, rotary barrel brush machine, automatic bucket machine, washing machine, normal pressure filling machine, capping machine, intelligent steam heat shrink machine, online inspection system, straight-line pail bagging machine, and a palletizing machine. All these components are connected via a conveying system to create a continuous, streamlined operation.

Advantages of the Automatic Liquid Filling Machine

High Efficiency: Automatic liquid filling machines significantly increase production speed and efficiency, reducing the time required to fill containers compared to manual methods.

Precision and Consistency: These machines ensure accurate and consistent filling volumes, minimizing product waste and ensuring uniformity across all filled containers.

Versatility: Designed to handle various types of liquids, from water and juice to more viscous substances, automatic liquid filling machines can be easily adjusted to accommodate different product requirements.

Hygiene and Safety: With automated systems, there is less human contact with the product, which enhances hygiene and reduces the risk of contamination. Additionally, safety features are often built into the machines to protect operators.

Scalability: Automatic liquid filling machines can be easily integrated into larger production lines and scaled up to meet increasing production demands.

Reduced Labor Costs: By automating the filling process, businesses can reduce labor costs and reallocate workforce to other areas of production that may require human intervention.

Ease of Operation and Maintenance: Modern automatic liquid filling machines come with user-friendly interfaces and require minimal maintenance, making them easy to operate and maintain over time.

Customizability: These machines can be customized to fit specific production needs, including different bottle sizes, shapes, and materials, providing flexibility for manufacturers.
